wAP ax

MikroTik

wAP ax

รหัสสินค้า: wAPG-5HaxD2HaxD

จุดเชื่อมต่อ Wi-Fi 6 สำหรับสภาพแวดล้อมท้าทาย พอร์ต Gigabit, กันน้ำกันฝุ่น

  • ARM
  • 1G
  • v7
  • Wi-Fi 6
THB 6,408.00
MikroTik wAP ax—
THB 6,408.00

จุดเด่น

  • Wi-Fi 6
  • Rugged
  • Outdoor
  • RouterOS

ภาพรวมสินค้า

wAP ax brings fast and reliable Wi-Fi 6 to your countryside getaway or any other challenging environments – like a rural gas station or a bus stop.
wAP ax brings fast and reliable Wi-Fi 6 to your countryside getaway or any other challenging environments – like a rural gas station or a bus stop.

ข้อมูลจำเพาะ

Specifications

Product code
wAPG-5HaxD2HaxD
Suggested price
$89.00
Architecture
ARM 32bit
CPU
IPQ-5010
CPU core count
2
CPU nominal frequency
800 MHz
CPU Threads count
2
RouterOS license
4
Operating System
RouterOS v7
Size of RAM
256 MB
Storage size
128 MB
Storage type
NAND
MTBF
Approximately 100'000 hours at 25C
Tested ambient temperature
-40°C to 70°C

Wireless capabilities

Wireless 2.4 GHz Max data rate
574 Mbit/s
Wireless 2.4 GHz Number of chains
2
Wireless 2.4 GHz standards
802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz
6.9
Wireless 2.4 GHz chip model
IPQ-5010
Wireless 2.4 GHz generation
Wi-Fi 6
Wireless 5 GHz Max data rate
2400 Mbit/s
Wireless 5 GHz Number of chains
2
Wireless 5 GHz standards
802.11a/n/ac/ax
Antenna gain dBi for 5 GHz
7
Wireless 5 GHz chip model
QCN-6102
Wireless 5 GHz generation
Wi-Fi 6
WiFi speed
AX3000

Ethernet

10/100/1000 Ethernet ports
2

Powering

Number of DC inputs
2 (DC jack, PoE-IN)
DC jack input Voltage
12-57 V
Max power consumption
9 W
Max power consumption without attachments
9 W
PoE in
802.3af/at
Cooling type
Passive
PoE in input Voltage
18-57 V

Certification & Approvals

Certification
CE, FCC, IC, EAC, ROHS
IP
54

Other

CPU temperature monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes
