MikroTik

hAP ax S

รหัสสินค้า: E62iUGS-2axD5axT

จุดเชื่อมต่อ Wi-Fi 6 พอร์ต Gigabit 5 พอร์ต, SFP 2.5G, PoE-in/out, CPU ARM Dual-core

  • SFP
  • in+out
  • ARM
  • mixed
  • v7
THB 5,688.00
MikroTik hAP ax S
THB 5,688.00

จุดเด่น

  • Triple-chain 5 GHz
  • 2.5G SFP Port
  • Wi-Fi 6 radio (Dual-Band)
  • 5 × Gigabit Ethernet
  • PoE-in + PoE-out
  • RouterOS v7
  • Dual-Core ARM CPU

ภาพรวมสินค้า

It costs far less than most mid-range, mass-produced routers… while delivering far more flexibility and longevity right out of the box!

The new hAP ax S features a triple-chain 5 GHz radio that achieves real-world throughput of around 800–900 Mbit/s. That means smooth streaming, faster downloads, and stable performance across multiple devices – even in crowded environments.

It’s also perfect as a dedicated Wi-Fi 6 VR streaming access point for PC VR headsets, offering higher resolution and lower latency without the cables. Unlike single-purpose “gaming” access points, the hAP ax S gives you the full performance, flexibility, and future-proofing of RouterOS v7!

Enjoy dual powering options – DC jack or PoE-in – and a passive PoE-out port to power another MikroTik device, such as an additional AP or a compact desktop switch. This makes it ideal for both home setups and small offices where clean cable management matters.

ข้อมูลจำเพาะ

Specifications

Product code
E62iUGS-2axD5axT
Suggested price
$79.00
Architecture
ARM 32bit
CPU
EN7562CT
CPU core count
2
CPU nominal frequency
950 MHz
CPU Threads count
2
Switch chip model
EN7523
RouterOS license
4
Operating System
RouterOS v7
Size of RAM
512 MB
Storage size
128 MB
Storage type
NAND
MTBF
Approximately 100'000 hours at 25C
Tested ambient temperature
-40°C to 70°C

Wireless capabilities

Wireless 2.4 GHz Max data rate
574 Mbit/s
Wireless 2.4 GHz Number of chains
2
Wireless 2.4 GHz standards
802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz
5.5
Wireless 2.4 GHz chip model
MT7916
Wireless 2.4 GHz generation
Wi-Fi 6
Wireless 5 GHz Max data rate
2400 Mbit/s
Wireless 5 GHz Number of chains
3
Wireless 5 GHz standards
802.11a/n/ac/ax
Antenna gain dBi for 5 GHz
6.5
Wireless 5 GHz chip model
MT7976
Wireless 5 GHz generation
Wi-Fi 6
WiFi speed
AX3000

Ethernet

10/100/1000 Ethernet ports
5
Number of 1G Ethernet ports with PoE-out
1

Fiber

SFP ports
1 (2.5G supported)

Peripherals

Number of USB ports
1
USB Power Reset
Yes
USB slot type
USB type A
Max USB current (A)
1

Powering

Number of DC inputs
2 (DC jack, PoE-IN)
DC jack input Voltage
12-28 V
Max power consumption
34 W
Max power consumption without attachments
11 W
PoE in
Passive PoE
Cooling type
Passive
PoE in input Voltage
18-28 V

PoE-out

PoE-out ports
Ether5
PoE out
Passive PoE
Low voltage PoE-Out current limit
0.6 A
Max total out (A)
0.6 A
Total output current
0.6
Total output power
16.8

Certification & Approvals

Certification
CE, FCC, IC, EAC, ROHS
IP
20

Other

CPU temperature monitor
Yes
