RB4011iGS+5HacQ2HnD-IN

MikroTik

RB4011iGS+5HacQ2HnD-IN

รหัสสินค้า: RB4011iGS+5HacQ2HnD-IN

เราเตอร์ 10 พอร์ต Gigabit, SFP+ 10G, CPU Quad-core 1.4GHz, แรม 1GB, Wi-Fi 5 4x4 MIMO

  • SFP+
  • ARM
  • 1G
  • v7
  • Wi-Fi
THB 19,800.00
MikroTik RB4011iGS+5HacQ2HnD-IN—
THB 19,800.00

จุดเด่น

  • 10Gigabit
  • SFP+
  • Quad-core
  • 1GB RAM
  • Wi-Fi 5
  • RouterOS

ภาพรวมสินค้า

Powerful 10xGigabit port router with a Quad-core 1.4Ghz CPU, 1GB RAM, SFP+ 10Gbps cage, dual band 2.4GHz / 5GHz 4x4 MIMO 802.11a/b/g/n/ac wireless and desktop case
Powerful 10xGigabit port router with a Quad-core 1.4Ghz CPU, 1GB RAM, SFP+ 10Gbps cage, dual band 2.4GHz / 5GHz 4x4 MIMO 802.11a/b/g/n/ac wireless and desktop case

ข้อมูลจำเพาะ

Specifications

Product code
RB4011iGS+5HacQ2HnD-IN
Suggested price
$275.00
Architecture
ARM 32bit
CPU
AL21400
CPU core count
4
CPU nominal frequency
auto (533 - 1900) MHz
CPU Threads count
4
Switch chip model
RTL8367SB
Dimensions
228 x 120 x 30 mm
RouterOS license
5
Operating System
RouterOS v7
Size of RAM
1 GB
Storage size
512 MB
Storage type
NAND
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-40°C to 45°C

Wireless capabilities

Wireless 5 GHz Max data rate
1733 Mbit/s
Wireless 5 GHz Number of chains
4
Wireless 5 GHz standards
802.11a/n/ac
Antenna gain dBi for 5 GHz
3
Wireless 5 GHz chip model
QCA9984
Wireless 5 GHz generation
Wi-Fi 5
Wireless 2.4 GHz Max data rate
300 Mbit/s
Wireless 2.4 GHz Number of chains
2
Wireless 2.4 GHz standards
802.11b/g/n
Antenna gain dBi for 2.4 GHz
3
Wireless 2.4 GHz chip model
R11e-2HnD
Wireless 2.4 GHz generation
Wi-Fi 4
WiFi speed
AC2000

Ethernet

10/100/1000 Ethernet ports
10

Fiber

SFP+ ports
1

Peripherals

MiniPCI-e slots
1
Serial console port
RJ45

Powering

Number of DC inputs
2 (DC jack, PoE-IN)
DC jack input Voltage
12-57 V
Max power consumption
44 W
Max power consumption without attachments
23 W
PoE in
Passive PoE
Cooling type
Passive
PoE in input Voltage
18-57 V

PoE-out

PoE-out ports
Ether10
PoE out
Passive PoE up to 57V
Low voltage PoE-Out current limit
600 mA
High voltage PoE-Out current limit
420 mA
Max total out (A)
600 mA

Certification & Approvals

Certification
CE, FCC, IC, EAC, ROHS
IP
IP20

Other

PCB temperature monitor
Yes
Voltage Monitor
Yes

เอกสาร

brochure

เปิดเอกสารจากผู้ผลิตเพื่อดูรายละเอียดสเปกและฟีเจอร์

PDF
