KNOT

MikroTik

KNOT

รหัสสินค้า: RB924i-2nD-BT5&BG77

IoT Gateway สำหรับการตั้งค่าที่หลากหลายและคุ้มค่า

THB 7,128.00
MikroTik KNOT—
THB 7,128.00

จุดเด่น

  • IoT
  • Gateway

ภาพรวมสินค้า

IoT Gateway for the most versatile and cost-effective setups
IoT Gateway for the most versatile and cost-effective setups

ข้อมูลจำเพาะ

Specifications

Product code
RB924i-2nD-BT5&BG77
Suggested price
$99.00
Architecture
MIPSBE
CPU
QCA9531
CPU core count
1
CPU nominal frequency
650 MHz
Switch chip model
QCA9531
Dimensions
122 x 87 x 26 mm
RouterOS license
4
Operating System
RouterOS v7
Size of RAM
64 MB
Storage size
128 MB
Storage type
NAND
MTBF
Approximately 100'000 hours at 25C
Tested ambient temperature
-40°C to 70°C

Powering

MicroUSB input Voltage
5 V
Number of DC inputs
3 (DC jack, PoE-IN, MicroUSB)
DC jack input Voltage
12-57 V
Max power consumption
18 W
Max power consumption without attachments
5 W
PoE in
802.3af/at
Cooling type
Passive
PoE in input Voltage
18-57 V

PoE-out

PoE-out ports
Ether2
PoE out
Passive PoE up to 57V
Total output power
12

Wireless specifications

Wireless 2.4 GHz Max data rate
300 Mbit/s
Wireless 2.4 GHz Number of chains
2
Wireless 2.4 GHz standards
802.11b/g/n
Antenna gain dBi for 2.4 GHz
1.5
Wireless 2.4 GHz chip model
QCA9531
Wireless 2.4 GHz generation
Wi-Fi 4

Ethernet

10/100 Ethernet ports
2

Peripherals

Number of SIM slots
1 Modem (Nano SIM)
Serial console port
RS485
Number of USB ports
1
USB slot type
microUSB type AB
Max USB current (A)
1

Other

PCB temperature monitor
Yes
Voltage Monitor
Yes
Bluetooth version
5.2
Bluetooth RF connector type
uUFL

Certification & Approvals

Certification
CE, FCC, IC, EAC, ROHS
IP
IP20

เอกสาร

brochure

เปิดเอกสารจากผู้ผลิตเพื่อดูรายละเอียดสเปกและฟีเจอร์

PDF
