cAP ax

MikroTik

cAP ax

รหัสสินค้า: cAPGi-5HaxD2HaxD

จุดเชื่อมต่อไร้สายรุ่นใหม่ 802.11ax (Wi-Fi 6) พร้อม CPU quad-core, RAM 1GB, พอร์ต Gigabit Ethernet 2 พอร์ต, รองรับ PoE

  • in
  • 1G
  • Wi-Fi 6
THB 9,288.00
MikroTik cAP ax—
THB 9,288.00

จุดเด่น

  • Wi-Fi 6
  • 802.11ax
  • PoE
  • quad-core CPU
  • ceiling mount

ภาพรวมสินค้า

The best-selling ceiling access point is back – stronger than ever! A new generation of wireless greatness for your office, hotel, mall, or any other setups in crowded areas. Modern quad-core CPU, 1GB of RAM, 2x Gigabit Ethernet ports, PoE, Gen 6 802.11ax wireless, PSU – included!
The best-selling ceiling access point is back – stronger than ever! A new generation of wireless greatness for your office, hotel, mall, or any other setups in crowded areas. Modern quad-core CPU, 1GB of RAM, 2x Gigabit Ethernet ports, PoE, Gen 6 802.11ax wireless, PSU – included!

ข้อมูลจำเพาะ

Specifications

Product code
cAPGi-5HaxD2HaxD
Suggested price
$129.00
Architecture
ARM 64bit
CPU
IPQ-6010
CPU core count
4
CPU nominal frequency
auto (864 - 1800) MHz
CPU Threads count
4
Switch chip model
IPQ-6010
RouterOS license
4
Operating System
RouterOS v7
Size of RAM
1 GB
Storage size
128 MB
Storage type
NAND
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-40°C to 70°C

Wireless capabilities

Wireless 2.4 GHz Max data rate
574 Mbit/s
Wireless 2.4 GHz Number of chains
2
Wireless 2.4 GHz standards
802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz
6
Wireless 2.4 GHz chip model
QCN-5022
Wireless 2.4 GHz generation
Wi-Fi 6
Wireless 5 GHz Max data rate
1200 Mbit/s
Wireless 5 GHz Number of chains
2
Wireless 5 GHz standards
802.11a/n/ac/ax
Antenna gain dBi for 5 GHz
5.5
Wireless 5 GHz chip model
QCN-5052
Wireless 5 GHz generation
Wi-Fi 6
WiFi speed
AX1800

Ethernet

10/100/1000 Ethernet ports
2
Number of 1G Ethernet ports with PoE-out
1

Powering

Number of DC inputs
2 (DC jack, PoE-IN)
DC jack input Voltage
18-57 V
Max power consumption
36 W
Max power consumption without attachments
11 W
PoE in
802.3af/at
Cooling type
Passive
PoE in input Voltage
18-57 V

PoE-out

PoE-out ports
Ether2
PoE out
Passive PoE up to 57V
Low voltage PoE-Out current limit
600 mA
High voltage PoE-Out current limit
400 mA
Max total out (A)
600 mA
Total output current
0.4
Total output power
19.2

Certification & Approvals

Certification
CE, FCC, IC, EAC, ROHS
IP
20

Other

CPU temperature monitor
Yes
Mode button
Yes
