hAP ac²

MikroTik

hAP ac²

รหัสสินค้า: RBD52G-5HacD2HnD-TC

เราเตอร์ดูอัลแบนด์ 2.4/5GHz พร้อม 5 พอร์ต Gigabit Ethernet, USB สำหรับ 3G/4G, รองรับ IPsec hardware encryption

  • 1G
  • Wi-Fi
THB 5,688.00
MikroTik hAP ac²—
THB 5,688.00

จุดเด่น

  • Gigabit
  • IPsec
  • Dual-band
  • USB

ภาพรวมสินค้า

Dual-Concurrent 2.4/5GHz AP, 802.11a/b/g/n/ac, Five Gigabit Ethernet ports, USB for 3G/4G support, universal tower case and IPsec hardware encryption support
Dual-Concurrent 2.4/5GHz AP, 802.11a/b/g/n/ac, Five Gigabit Ethernet ports, USB for 3G/4G support, universal tower case and IPsec hardware encryption support

ข้อมูลจำเพาะ

Specifications

Product code
RBD52G-5HacD2HnD-TC
Suggested price
$79.00
Architecture
ARM 32bit
CPU
IPQ-4018
CPU core count
4
CPU nominal frequency
488-896 (auto) MHz
CPU Threads count
4
Switch chip model
IPQ-4018
Dimensions
34 x 119 x 98mm
RouterOS license
4
Operating System
RouterOS
Size of RAM
128 MB
Storage size
16 MB
Storage type
FLASH
MTBF
Approximately 100'000 hours at 25C
Tested ambient temperature
-40°C to 50°C

Wireless capabilities

Wireless 2.4 GHz Max data rate
300 Mbit/s
Wireless 2.4 GHz Number of chains
2
Wireless 2.4 GHz standards
802.11b/g/n
Antenna gain dBi for 2.4 GHz
2.5
Wireless 2.4 GHz chip model
IPQ-4018
Wireless 2.4 GHz generation
Wi-Fi 4
Wireless 5 GHz Max data rate
867 Mbit/s
Wireless 5 GHz Number of chains
2
Wireless 5 GHz standards
802.11a/n/ac
Antenna gain dBi for 5 GHz
2.5
Wireless 5 GHz chip model
IPQ-4018
Wireless 5 GHz generation
Wi-Fi 5
WiFi speed
AC1200

Ethernet

10/100/1000 Ethernet ports
5

Peripherals

Number of USB ports
1
USB Power Reset
Yes
USB slot type
USB type A
Max USB current (A)
1

Powering

Number of DC inputs
2 (DC jack, PoE-IN)
DC jack input Voltage
12-30 V
Max power consumption
21 W
Max power consumption without attachments
16 W
PoE in
Passive PoE
Cooling type
Passive
PoE in input Voltage
18-28 V

Certification & Approvals

Certification
CE, FCC, IC, EAC, ROHS
IP
IP20

Other

Mode button
Yes

เอกสาร

brochure

เปิดเอกสารจากผู้ผลิตเพื่อดูรายละเอียดสเปกและฟีเจอร์

PDF
