RB5009UPr+S+OUT

MikroTik

RB5009UPr+S+OUT

รหัสสินค้า: RB5009UPr+S+OUT

เราเตอร์ PoE กลางแจ้ง, 7 พอร์ต Gigabit, 1 พอร์ต 2.5G, SFP+ 10G, กันน้ำ IP66, 9 ตัวเลือกไฟเลี้ยง

  • SFP+
  • in+out
  • mixed
THB 22,968.00
MikroTik RB5009UPr+S+OUT—
THB 22,968.00

จุดเด่น

  • PoE
  • outdoor
  • IP66
  • 2.5G
  • 10G
  • SFP+
  • redundant power

ภาพรวมสินค้า

An outdoor version of our best-selling heavy-duty PoE router. Extensive power redundancy for the best price! 7x Gigabit Ethernet ports, 1x 2.5 Gigabit Ethernet, 10G SFP+, 1GB of RAM, 1GB NAND, modern quad-core CPU, 9 (!) powering options, durable IP66 waterproof enclosure.
An outdoor version of our best-selling heavy-duty PoE router. Extensive power redundancy for the best price! 7x Gigabit Ethernet ports, 1x 2.5 Gigabit Ethernet, 10G SFP+, 1GB of RAM, 1GB NAND, modern quad-core CPU, 9 (!) powering options, durable IP66 waterproof enclosure.

ข้อมูลจำเพาะ

Specifications

Product code
RB5009UPr+S+OUT
Suggested price
$319.00
Architecture
ARM 64bit
CPU
88F7040
CPU core count
4
CPU nominal frequency
350-1400 (auto) MHz
CPU Threads count
4
Switch chip model
88E6393
RouterOS license
5
Operating System
RouterOS v7
Size of RAM
1 GB
Storage size
1 GB
Storage type
NAND
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-40°C to 70°C

Powering

Number of DC inputs
2 (PoE-IN, 2-pin terminal)
2-pin terminal input Voltage
24-57 V
Max power consumption
150 W
Max power consumption without attachments
15 W
PoE in
802.3af/at
Cooling type
Passive
PoE in input Voltage
24-57 V

PoE-out

PoE-out ports
Ether1-Ether8
PoE out
802.3af/at
Low voltage PoE-Out current limit
900 mA
High voltage PoE-Out current limit
440 mA
Max total out (A)
2.59 A
Total output current
2.28
Total output power
130

Ethernet

10/100/1000 Ethernet ports
7
Number of 1G Ethernet ports with Reverse PoE (PoE-in)
7
Number of 2.5G Ethernet ports
1
Number of 2.5G Ethernet ports with PoE-out
1

Fiber

SFP+ ports
1

Peripherals

Number of USB ports
1
USB Power Reset
Yes
USB slot type
USB 3.0 type A
Max USB current (A)
1.5

Other

CPU temperature monitor
Yes
Current Monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes

Certification & Approvals

Certification
CE, EAC, ROHS
IP
66

เอกสาร

brochure

เปิดเอกสารจากผู้ผลิตเพื่อดูรายละเอียดสเปกและฟีเจอร์

PDF
