hEX S (2025)

MikroTik

hEX S (2025)

รหัสสินค้า: E60iUGS

เราเตอร์แบบมีสายขนาดกะทัดรัด พอร์ต 2.5G SFP 1 พอร์ต, 5x Gigabit Ethernet, PoE out, USB, CPU dual-core

  • SFP
  • out
  • mixed
THB 4,968.00
MikroTik hEX S (2025)—
THB 4,968.00

จุดเด่น

  • 2.5G SFP uplink
  • 5 x 1G ethernet (bonding support)
  • PoE-In & PoE-Out
  • USB 3 port for storage & file sharing
  • Dual-Core ARM CPU + 512 MB RAM
  • Flexible powering (12–57 V)
  • RouterOS v7
  • Wall-mountable design

ภาพรวมสินค้า

Need a wired router that won’t slow you down or drain your budget? The new hEX S is a compact, truly budget-friendly device that does a little bit of everything — and does it fast. Whether you’re building a smart home, running a local lab, or just want a clean, powerful wired setup, this is your new Ethernet essential.

With 5× Gigabit Ethernet ports (including PoE-in on port #1 and PoE-out on port #5), plus a 2.5 Gigabit SFP cage, this compact router can adapt to many roles. And unlike most ISP boxes, you can assign any port as WAN, LAN, or bridge — full flexibility right out of the box. That’s just the beginning. RouterOS v7 gives you advanced routing, VLANs, bonding, traffic shaping, and more — so you can build the wired network you’ve always wanted.

hEX S — higher speed and better connectivity on a smaller budget.
Because every network deserves an upgrade.
hEX S — higher speed and better connectivity on a smaller budget.
Because every network deserves an upgrade.

ข้อมูลจำเพาะ

Specifications

Product code
E60iUGS
Suggested price
$69.00
Architecture
ARM 32bit
CPU
EN7562CT
CPU core count
2
CPU nominal frequency
950 MHz
CPU Threads count
2
Switch chip model
EN7523
RouterOS license
4
Operating System
RouterOS v7
Size of RAM
512 MB
Storage size
128 MB
Storage type
NAND
MTBF
Approximately 100'000 hours at 25C
Tested ambient temperature
-40°C to 70°C

Powering

Number of DC inputs
2 (DC jack, PoE-IN)
DC jack input Voltage
12-57 V
Max power consumption
23 W
Max power consumption without attachments
5 W
PoE in
802.3af/at
Cooling type
Passive
PoE in input Voltage
18-57 V

PoE-out

PoE-out ports
Ether5
PoE out
Passive PoE up to 57V
Low voltage PoE-Out current limit
0.5 A
High voltage PoE-Out current limit
0.5 A

Ethernet

10/100/1000 Ethernet ports
5
Number of 1G Ethernet ports with PoE-out
1

Fiber

SFP ports
1 (2.5G supported)

Peripherals

Number of USB ports
1
USB Power Reset
Yes
USB slot type
USB 3.0 type A
Max USB current (A)
1

Other

CPU temperature monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes
Mode button
Yes

Certification & Approvals

Certification
CE, EAC, ROHS
IP
20
