CRS320-8P-8B-4S+RM

MikroTik

CRS320-8P-8B-4S+RM

รหัสสินค้า: CRS320-8P-8B-4S+RM

สวิตช์ PoE++ 8 พอร์ต PoE out, 8 พอร์ต Gigabit, 4 พอร์ต SFP+ 10G, รองรับ 802.3af/at/bt

  • SFP+
  • out
  • ARM
  • 1G
  • v7
THB 35,208.00
MikroTik CRS320-8P-8B-4S+RM—
THB 35,208.00

จุดเด่น

  • PoE++
  • PoE out
  • SFP+
  • 802.3bt

ภาพรวมสินค้า

The first MikroTik high-power PoE++ switch – for easy
and cost-effective powering of industry standard 802.3af/at/bt devices. Forget about countless power cables – create a cleaner space with PoE++!
The first MikroTik high-power PoE++ switch – for easy and cost-effective powering of industry standard 802.3af/at/bt devices. Forget about countless power cables – create a cleaner space with PoE++!

ข้อมูลจำเพาะ

Specifications

Product code
CRS320-8P-8B-4S+RM
Suggested price
$489.00
Architecture
ARM 32bit
CPU
98DX226S
CPU core count
2
CPU nominal frequency
800 MHz
Switch chip model
98DX226S
RouterOS license
5
Operating System
RouterOS v7 / SwitchOS
Size of RAM
256 MB
Storage size
32 MB
Storage type
FLASH
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-10°C to 50°C

Powering

Number of AC inputs
1
AC input range
100-240
Number of PSU slots
2
Frequency (Hz)
50-60
Max power consumption
600W (1150W with additional PSU)
Max power consumption without attachments
36 W
Cooling type
3 fans

PoE-out

PoE-out ports
Ether1-Ether8 (af/at), Ether9-Ether16 (bt)
PoE out
802.3af/at/bt
High voltage PoE-Out current limit
560 (af/at) / 1667 (bt) mA
Max total out (A)
17.82 A
Total output current
17.82
Total output power
963

Ethernet

10/100/1000 Ethernet ports
17
Number of 1G Ethernet ports with PoE-out
16

Fiber

SFP+ ports
4

Peripherals

Serial console port
RJ45

Other

CPU temperature monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes

Certification & Approvals

Certification
CE, EAC, ROHS
IP
20

เอกสาร

brochure

เปิดเอกสารจากผู้ผลิตเพื่อดูรายละเอียดสเปกและฟีเจอร์

PDF
