CRS112-8P-4S-IN

MikroTik

CRS112-8P-4S-IN

รหัสสินค้า: CRS112-8P-4S-IN

สวิตช์อัจฉริยะ 8 พอร์ต Gigabit PoE-out, 4 พอร์ต SFP, CPU 400MHz, RAM 128MB, RouterOS L5

  • SFP
  • out
  • 1G
  • v6
THB 15,048.00
MikroTik CRS112-8P-4S-IN—
THB 15,048.00

จุดเด่น

  • PoE
  • SFP
  • RouterOS L5
  • smart switch
  • Gigabit

ภาพรวมสินค้า

8x Gigabit Ethernet Smart Switch with PoE-out, 4x SFP cages, 400MHz CPU, 128MB RAM, desktop case, RouterOS L5
8x Gigabit Ethernet Smart Switch with PoE-out, 4x SFP cages, 400MHz CPU, 128MB RAM, desktop case, RouterOS L5

ข้อมูลจำเพาะ

Specifications

Product code
CRS112-8P-4S-IN
Suggested price
$209.00
Architecture
MIPSBE
CPU
QCA8511
CPU core count
1
CPU nominal frequency
400 MHz
Switch chip model
QCA8511
Dimensions
200 x 142 x 44 mm
RouterOS license
5
Operating System
RouterOS
Size of RAM
128 MB
Storage size
16 MB
Storage type
FLASH
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-20°C to 60°C

Powering

Number of DC inputs
2 (DC jack)
DC jack input Voltage
18-28 V / 48-57 V
Max power consumption
160 W
Max power consumption without attachments
10 W
Cooling type
Passive

PoE-out

PoE-out ports
Ether1-Ether8
PoE out
802.3af/at
Low voltage PoE-Out current limit
1 A
High voltage PoE-Out current limit
450 mA
Max total out (A)
2.8A (18V-28V) & 1.4A (48V-57V) A

Ethernet

10/100/1000 Ethernet ports
8
Number of 1G Ethernet ports with PoE-out
8

Fiber

SFP ports
4

Peripherals

Serial console port
RJ45

Other

PCB temperature monitor
Yes

Certification & Approvals

Certification
CE, EAC, ROHS
IP
IP20

เอกสาร

brochure

เปิดเอกสารจากผู้ผลิตเพื่อดูรายละเอียดสเปกและฟีเจอร์

PDF
